Increased comfort and reduced environmental impact 12 to 540 Volts High-performance, compact, adaptable LOW CARBON EMISSIONS COMPACT SILENCE 12 TO 540 VOLTS EASY TO INSTALL PERFORMANCE LOW ENERGY CONSUMPTION COMFORT SKIMO SPLIT Electric split air conditioning systems The SKIMO SPLIT range of low-voltage electric air conditioning systems comprises an interior unit (heat exchanger) and an external unit (condenser). These units are connected via a bespoke refrigerated connection to suit the dimensions of the cabin. The SKIMO SPLIT range is designed for 100% electric vehicles or those vehicles that do not have any free space in the cabin or engine compartment. SKIMO SPLIT electric air conditioning systems offer the perfect compromise between performance and energy consumption. The wide range of interior units (of a reduced size) and external units (with a wide selection of voltages) offer countless configurations for the perfect installation. The system is charged with refrigerant by the installer. The SKIMO SPLIT range of low-voltage electric air conditioners does not require a compressor to be fitted to the motor. High-performance, compact and adaptable to most machines, SKIMO SPLIT is available as standard for cabins up to 4 m3 and temperatures from -10°C to 55°C. SKIMO SPLITs are available with electric air conditioning only or with electric air conditioning and heating. External Units The range of external units used in the SKIMO SPLIT system offers several supply voltage options, from 12 to 540 Volts DC. Designed for applications in both normal and tough conditions, these compact external units can be installed in various different configurations. ALIZE E From 12 to 540 V Cooling Capacity: 5.8 kW Power Consumption: 960 to 1,440 W Installation: Horizontal Max. Temp.: 55°C ALIZE HD 24 V Cooling Capacity: 6.6 kW Power Consumption: 1,440 to 2,160 W Installation: Horizontal or vertical Max. Temp.: 55°C Interior Units A large range of 100% metal interior units means you can select the optimum to connect to your chosen external unit and complete your SKIMO SPLIT system. These interior units are designed for tough applications in the most challenging environments. Heating & air conditioning or air-conditioning-only versions are available. BOREAL Dimensions: 415 x 360 x 147 mm Weight: 10 kg Installation: Vertical ZEPHYR Dimensions: 490 x 170 x 170 mm Weight: 8 kg Installation: Vertical BORA H Dimensions: 528 x 355 x 168 mm Weight: 14 kg Installation: Horizontal BORA V Dimensions: 530 x 461 x 172 mm Weight: 15 kg Installation: Vertical Request personalised assistance and you will be contacted by one of our SKIMO SPLIT specialists Compact solutions With their reduced size, the external unit (ALIZE E or ALIZE HD) and the interior unit (BOREAL, ZEPHYR, BORA V or BORA H) are easily combined on vehicles that do not have much free space. External unit dimensions: ALIZE HD: 770 x 550 x 232 mm ALIZE E: 690 x 420 x 233 mm Interior unit dimensions: BOREAL: 415 x 360 x 147 mm ZEPHYR: 490 x 170 x 170 mm BORA V: 530 x 461 x 172 mm BORA H: 528 x 355 x 168 mm Performances Performance at 38°C After 5 minutes of operation: The blower temperature : 14.1 °C The cabin temperature : 32 °C After 1 hour of operation: The blower temperature : 6.3 °C The cabin temperature : 25.4 °C. The difference between the test chamber temperature and the temperature inside the cabin is 12.7°C. Performances à 43 °C After 5 minutes of operation: The blower temperature : 17.5 °C The cabin temperature : 35.4°C After 1 hour of operation: The blower temperature : 9.9 °C The cabin temperature : 29.8 °C. The difference between the test chamber temperature and the temperature inside the cabin is 13.6°C. Sectors By separating the heat exchanger and external units, this system can be easily installed in a range of configurations according to the available space. The compressor-condenser assembly can be installed vertically on the side of the cabin or horizontally on the hood or canopy. The heat exchanger will be installed inside the cabin. The SKIMO SPLIT is particularly suitable for the following: electric forklifts industrial forklifts electric commercial vehicles maintenance vehicles all types of vehicle or machine using a battery up to 100V. Reliability Endurance Tests Before being put on the market, the SKIMO SPLIT system was subject to endurance tests that reproduced the expected usage conditions. The SKIMO SPLIT system was tested and analysed in a climatic chamber and subjected to extreme variations in temperature. Production Tests During production, 100% of SKIMO SPLIT systems are tested on an automated test rig. Every single SKIMO SPLIT system is subject to rigorous testing on an automated test rig. Warranty The warranty for this range is valid for 2 years or 2,000 operating hours. The warranty does not cover consumables, wear and tear or damage resulting from incorrect use, including in the following cases: Use in an abnormally humid environment Use in a highly saline environment Use in a highly acidic environment High-pressure cleaning and/or the use of detergents
